8 Mbit Firmware Hub
A Microchip Technology Company
SST49LF008A
Data Sheet
Firmware Hub (FWH) Mode
Device Operation
The FWH mode uses a 5-signal communication interface, FWH[3:0] and FWH4, to control operations
of the SST49LF008A. Operations such as Memory Read and Memory Write uses Intel FWH propriety
protocol. JEDEC Standard SDP (Software Data Protection) Byte-Program, Sector-Erase and Block-
Erase command sequences are incorporated into the FWH memory cycles. Chip-Erase is only avail-
able in PP Mode.
The device enters standby mode when FWH4 is high and no internal operation is in progress. The
device is in ready mode when FWH4 is low and no activity is on the FWH bus.
Firmware Hub Interface Cycles
Addresses and data are transferred to and from the SST49LF008A by a series of “fields,” where each
field contains 4 bits of data. SST49LF008A supports only single-byte Read and Write, and all fields are
one clock cycle in length. Field sequences and contents are strictly defined for Read and Write opera-
tions. Addresses in this section refer to addresses as seen from the SST49LF008A’s “point of view,”
some calculation will be required to translate these to the actual locations in the memory map (and
vice versa) if multiple memory devices are used on the bus. Tables 3 and 4 list the field sequences for
Read and Write cycles.
?2011 Silicon Storage Technology, Inc.
9
DS25085A
10/11
